Technical Data:
- Code: PGTVIPER-02/01-SCA-40
- Fiber Type: G.657.A1
- Color: White
- Outer Shell: LSOH (Low Smoke Zero Halogen)
- Diameter: 3.1 x 2.1 mm (Flat)
- Number of Fibers: 2
- Connector Type: 1x SC/APC
- Length: 40 meters
- Weight: 0.36 kg for shipment, 9 kg/km (±10%)
- Installation Temperature Range: -20 to +60°C
- Operating Temperature Range: -30 to +60°C
- Storage Temperature Range: -30 to +60°C
Features:
- Outer Shell: LSOH material ensures safety within buildings
- Design: Completely dielectric and capable of being pulled through conduits
- Accessibility: Provides easy access to fibers for maintenance
- Condition: Arrives completely dry with ready-made sections and prefabricated joints on one side
- Cable Stripping: Tool-free stripping at any length for user convenience
Application:
This VIPER 2J Pigtail is specifically designed for in-building use as a drop subscriber cable, particularly suitable for multi-family residential structures. The cable's flat design permits straightforward installation on walls, through electrical installation pipes, or within cable shafts, providing a reliable and efficient connection to the fiber optic network.
