ADSS Cable 96FO A-DQ(T)2Y 8X12 E9U LT2.3 up to 200m span

The ADSS Aramid Single Jacket Cable is an all-dielectric self-supporting aerial cable designed for telecommunications applications. This cable is specifically designed for medium span applications, with a maximum span length of up to 200 meters. It features a loose tube design with aramid strength members and a single HDPE jacket. With 8x12 fibres, the cable offers reliable connectivity and low attenuation over a wide wavelength range. The SMF-28e+® Ultra ITU G652.D ITU G657.A1 LT 2.3 compliant optical fibres ensure high performance.
SKU: 11
Availability: Currently out of Stock
*

Technical Data:

  • Cable Type: ADSS Aramid Single Jacket Cable
  • Maximum Span Length: Up to 200 meters
  • Fibre Count: 8x12 fibres
  • Fibre Type: SMF-28e+® Ultra ITU G652.D ITU G657.A1 LT 2.3
  • Temperature Range: -40°C to 70°C (operation), -40°C to -40°C (storage)
  • Crush Resistance: 2000 N/10 cm
  • Tensile Strength: 4240 N (long-term), 6880 N (short-term)
  • Bend Radius: 162 mm (installation), 216 mm (operation)
  • Outer Diameter: 10.8 mm
  • Attenuation: 0.34 dB/km (maximum)
  • Coating Diameter: 242 µm
  • Weight: 88 kg/km

Features:

  • All-dielectric self-supporting aerial cable
  • Stable performance over a wide temperature range
  • High fibre count with 8x12 fibres for enhanced connectivity
  • Low attenuation and compliance with ITU standards for optimal signal transmission
  • Innovative waterblocking materials for efficient installation
  • Easy, one-step installation using standard hardware and methods
  • Aramid strength members for enhanced durability
  • HDPE jacket for telecom applications

Applications:
The ADSS Aramid Single Jacket Cable is suitable for various telecommunications applications, including:

  • Campus backbones
  • Self-supporting installations where metallic messengers cannot be used
  • Telecom infrastructure projects requiring medium-span connectivity
  • Outdoor installations in different environmental conditions
  • Reliable and high-performance fiber optic networks
