Parameters:
resistant to UV radiation
durable and solid lightweight construction
enables customer connection with B3ND subscriber cables
large slack of subscriber cable (3mm) - 40m
inputs for 5-32mm installation pipes and cable trays
Use:
indoor installations
intermediate distribution point
Equipment included:
rubber gland - 3 pcs
ANT tray for 12 splices - 1 pc
ANT tray lid - 1 pc
foam tape - 1 pc (2mmx15mmx150mm)
lock with 2 keys - 1 set
panel adapter for 6 SC DX adapters - 1 pcÂ
door seal - 1 pc
descriptive sticker - 1 pc
Additional technical parameters:
dimensions [mm]: 210x180x60
color: Gray RAL 7035
weight 0.4 kg
leakage class: IP-44
mechanical protection rate: IK-10
max. number of SC DX adapters: 6 pcs
FEATURES:
-
Material UV resistant
-
Polycarbonate (PC) colour
-
RAL 7035
-
Indoor applicati on
-
IP 44
-
Capacity 6 adapters SC duplex (12 SC), 12 splices, storage for 40m cable (3mm)
-
Easy removable adapter panel
-
Easy access to splice tray
-
Light and small constructi on
-
4 entries for ducts 8-32mm from up and down, 6 entries from sides for square ducts
ADDITIONAL EQUIPMENT
SPLICE TRAY, ADAPTERS, CABLE GLANDS PG-29, CABLE TIES
