DUCT CABLE 72F - duct cable,6x12F,G652D,LT,central FRP,diameter 10,6mm

Manufacturer: ZTT
The GYFTY-72 G.652D is a robust, duct installation cable designed to house 72 optical fibers within its loose tubes, while being safeguarded by a UV-proof black PE outer sheath and water blocking components for reliable data transmission.
SKU: FTL01ZT0028
Availability: Currently out of Stock

Technical Data:
Fiber Count: 72 fibers
Loose Tubes: 6 tubes with 12 fibers each
Outer Sheath Thickness: Min. 1.8 mm
Outer Diameter: 10.6 mm (±0.4)
Cable Weight: 90 kg/km
Max. Tensile Load: 1500 N
Crush Resistance: 1000 N/10cm

Fiber Type: ITU-T G.652D ZTT-ALF® with low attenuation rates (?0.38 dB/km at 1310 nm and ?0.23 dB/km at 1550 nm)
Temperature Range: Operational from -30 to +70°C, installation from -20 to +60°C, and storage from -5 to +50°C
Water blocking yarns and tape for added protection
Central strength member made from fiber reinforced plastic (FRP) for structural integrity

The GYFTY-72 G.652D is ideally suited for duct installation applications, providing a secure and stable medium for long-distance communication. Its construction ensures optimal performance for telecommunications, internet backbone, and any scenario where high fiber count and minimal environmental interference are required.
