Technical Data:
Fiber Count: 2 fibers
Fiber Type: ITU-T G.657A1
Outer Diameter: 2.4mm ± 0.2mm
Weight: Approximately 5kg/km
Max. Tensile Load: 80N
Crush Resistance: 500N/10cm
Bending Radius: 90mm (installation), 50mm (operation)
Temperature Range: -20°C to +60°C (operation), -5°C to +40°C (installation)
Features:
Equipped with high-quality G.657A1 fibers for excellent transmission performance.
Incorporates aramid yarns for added tensile strength.
UV-resistant black HDPE outer sheath with a ripcord for easy access to fibers.
Inkjet or laser-printed markings at 1-meter intervals for precise measurements.
Application:
Ideal for expansive network installations where space is at a premium, the DUCT MICRO CABLE 2F is specifically designed for blowing into microducts with an outer diameter of 7 to 4mm, making it suitable for a variety of indoor and outdoor telecommunication applications.
