Technical Data:
Category: CAT5e
Cable Type: U/UTP (unshielded twisted pair)
Inner Conductor Material: Copper-clad aluminum (CCA)
Conductor Core Diameter: 7/0.13 ± 0.008 mm
Shielding Class: U/UTP
Cable Sheath Diameter: O 4.6 ± 0.3 mm, made of PVC
Connectors: RJ45 male (8P8C) on both ends
Maximum Bandwidth: 100 MHz
Color: Red
Length: 3 meters with a tolerance of ± 60 mm
Features:
Features high-quality copper-clad aluminum wires for reliable data transmission.
Equipped with latch protection on both ends to prevent accidental unplugging.
The cable's outer sheath is made of durable PVC to withstand common wear and tear.
Clearly marked with length indication on the slimline strain relief for easy identification.
Application:
Ideal for networking tasks in homes and offices, this cable can be used to connect computers, switches, routers, and other network components that require a stable Gigabit (10/100/1000 Mbit) connection. It supports network applications up to 100 MHz, making it suitable for various data transmission needs.
