Technical Data:
Operating frequency: 83.0, 101.4, 121.6, 134.0, 145.7 kHz
Top cover material: Polyethylene (PE)
Dimensions: 17 mm diameter × 100 mm height
Weight: Maximum 30 grams
Serial ID number: Yes, 10-digit hexadecimal code
ID reading range: 1.3 meters (vertical), 1.0 meter (horizontal)
Operating temperature: -20 °C to +60 °C
Marker lifetime including data: 50 years
Features:
Compact underground marker with pre-programmed ID number
Detectable in both vertical and horizontal positions
Supports assignment of text and image data
Compatible with Marker Database® PC software and mobile application
Designed for direct attachment to 7/4 mm microducts using optical coupler
Adaptable to other duct sizes via reducers
Durable construction with long-term data retention
Applications:
In optical network installations, the marker is designed to attach directly to 7/4 mm microducts using an optical coupler. It can also be adapted to other duct sizes with the use of reducers. Beyond telecommunications, the marker is suitable for identifying critical underground points at shallow depths, such as utility junctions or infrastructure components.
