Technical Data:
Fiber type: Single-mode (SM)
Fiber count: 1 G.657A1
Connector type: SC/UPC-SC/APC
Cable Length: 60 meters
Sheath type: LSZH (Low Smoke Zero Halogen)
Cable OD: 2.0±0.2mm*5.0±0.2mm
Operation temperature range: -20°C to +70°C
Max. tensile load: Short term - 800N; Long term - 500N
Features:
Superior quality control and reliability ensured by rigorous testing
Designed, manufactured, and tested according to international standards (IEC 61754-04 for the connector)
Excellent mechanical and environmental properties
Good bending performance for easy installation
Low insertion loss and high return loss
Applications:
This optical patch cord can be used in a variety of telecommunications and data networking applications including fiber-to-the-home (FTTH), LAN/WAN, and others where long-distance data transmission is required. It is particularly well-suited for environments where safety is a priority, thanks to its LSZH sheath.
