Technical Data:
Frequency Range: 0.3 - 3000 MHz
Impedance: 75 ?
Transfer Impedance: Class A++ (<0.9 m?/m at 5-30 MHz, <0.02 m?/item at 5-30 MHz)
Screening Attenuation: Class A++ (>130 dB at 30-1000 MHz)
Return Loss: -36 dB to -26 dB (depending on frequency range)
Insertion Loss: Better than typical values across frequency ranges
Temperature Range:
Installing: -5° to +50° C
Operating: -40° to +70° C
Storing: -40° to +70° C
Materials:
Body Parts: Zinc
Inner Conductor: Tin
Plating: Nitin
Insulators: PE
Features:
Wide frequency range of 0.3 to 3000 MHz
High screening attenuation and transfer impedance (Class A++)
Low insertion and return loss across various frequency ranges
Durable construction with high-quality materials (Zinc, Tin, Nitin)
Operates effectively in temperatures ranging from -40°C to +70°C
ISO 9001 and ISO 14001 certified production
Application:
The TR-59-1/4-HQ NiTin adapter is suitable for a variety of applications, including:
High-frequency communication systems
Broadcast and satellite systems
Any environment requiring high screening attenuation and low signal loss
Industrial and commercial installations requiring robust and reliable connectors
